744071056 Power Choke, 5.6uH, 4A, 31MHZ Wurth Elektronik

WURTH ELEKTRONIKUGS :744071056 Code de commande:2114325

Prix:
Prix ​​promotionnel€3,50

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (91 unité)

Documents et téléchargements

description

WURTH ELEKTRONIK - 744071056 - Power Inductor (SMD), 5.6 µH, 4 A, Shielded, 4 A, WE-TPC

  • Inductance: 5.6µH
  • RMS Current (Irms): 4A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 4A
  • Product Range: WE-TPC Series
  • Power Inductor Case: 8mm x 8mm x 4.3mm
  • DC Resistance Max: 0.025ohm
  • Inductance Tolerance: ± 30%
  • SVHC: No SVHC (15-Jan-2019)
  • Resonant Frequency: 31MHz
  • Self Resonant Frequency Min: 31MHz
