description
- Inductance: 3.3µH
- RMS Current (Irms): 5.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 4.7A
- Product Range: WE-TPC Series
- Power Inductor Case: 10mm x 10mm x 2.8mm
- DC Resistance Max: 0.02ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Self Resonant Frequency Min: 55MHz
