WURTH ELEKTRONIK - 744043005 - Power Inductor (SMD), 5.6 µH, 1.38 A, Shielded, 1.3 A, WE-TPC, 4.8mm x 4.8mm x 2.8mm
- Inductance: 5.6µH
- RMS Current (Irms): 1.38A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.3A
- Product Range: WE-TPC Series
- Power Inductor Case: 4.8mm x 4.8mm x 2.8mm
- DC Resistance Max: 0.085ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Resonant Frequency: 60MHz
- Self Resonant Frequency Min: 60MHz
