ALPHA WIRE - 5420/7 SL005 - Multicore Cable, Xtra Guard® 1, Unscreened, 7 Core, 20 AWG, 0.56 mm², 100 ft, 30.5 m
- Cable Shielding: Unscreened
- No. of Cores: 7Core
- Wire Gauge: 20AWG
- Conductor Area CSA: 0.56mm²
- Reel Length (Imperial): 100ft
- Reel Length (Metric): 30.5m
- Jacket Colour: Slate
- No. of Max Strands x Strand Size: 10 x 0.255mm
- Conductor Material: Copper
- Jacket Material: PVC
- External Diameter: 12.1mm
- Voltage Rating: 600V
- Product Range: 5420 Series
- SVHC: No SVHC (15-Jan-2019)
- Cable Type: Foil Shield
- Conductor Make-up: 10 / 30AWG
- Outer Diameter: 12.1mm
- Shield Material: Foil
- Shield Type: Shielded
- Wire Size: 20AWG
