MARL - 538-501-63 - LED Panel Mount Indicator, Weatherproof, Red, 28 VDC, 12.7 mm, 16 mA, 11 cd, IP67
- LED Colour: Red
 - Operating Voltage: 28VDC
 - Mounting Hole Dia: 12.7mm
 - Forward Current If: 16mA
 - Luminous Intensity: 11cd
 - IP / NEMA Rating: IP67
 - Product Range: 12.7mm Panel Mount LED 538 Series
 - SVHC: No SVHC (15-Jan-2019)
 - Behind Panel Depth: 29mm
 - Bezel Diameter: 17mm
 - Current If Min: 8mA
 - Fixing Hole Diameter: 13mm
 - Forward Current If Max: 16mA
 - Forward Voltage: 28V
 - Lead Length: 5mm
 - Lens Colour: Colour Diffused
 - Luminous Intensity @ If = 20mA: 11000mcd
 - Luminous Intensity Typ: 11000mcd
 - Material: Stainless Steel
 - Operating Temperature Max: 95°C
 - Operating Temperature Min: -40°C
 - Operating Temperature Range: -40°C to +95°C
 - Panel Cutout Diameter: 13mm
 - Peak Forward Current: 20mA
 - Reverse Protection Voltage: 1000VDC
 - Storage Temperature Max: 100°C
 - Storage Temperature Min: -40°C
 - Supply Voltage Max: 28VDC
 - Supply Voltage Min: 12VDC
 - Wavelength Typ: 643nm
