RUBYCON - 50YXM4R7MEFC5X11 - Electrolytic Capacitor, Miniature, 4.7 µF, 50 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 4.7µF
- Voltage Rating: 50V
- Product Range: YXM Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 5mm
- Lead Spacing: 2mm
- Height: 11mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 11mm
- Frequency Tolerance: 120Hz
- Lead Diameter: 0.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +105°C
- Operating life Time: 10000h
- Ripple Current AC: 80mA
- Ripple Current Frequency: 100kHz
- Ripple Current Temperature: 105°C
- Tolerance +: 20%
- Tolerance -: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 50V
- Voltage Rating VAC: 50V
