RUBYCON - 50RX3010M8X11.5 - Electrolytic Capacitor, Miniature, 10 µF, 50 V, ± 20%, Radial Leaded, 2000 hours @ 130°C, Polar
- Capacitance: 10µF
- Voltage Rating: 50V
- Product Range: RX30 Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 8mm
- Lead Spacing: 3.5mm
- Height: 11.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 130°C
- Lifetime @ Temperature: 2000 hours @ 130°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 11.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +130°C
- Operating life Time: 4000h
- Ripple Current AC: 200mA
- Tolerance -: 20%
- Voltage Rating V DC: 50V
