MYRRA - 48025 - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 3 W, 15 V, 200 mA
- No. of Outputs: 1 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Fixed
- Input Voltage VAC: 85V AC to 265V AC
- Width: 25mm
- Height: 16mm
- Depth: 25mm
- Product Range: 48000 Series
- SVHC: No SVHC (27-Jun-2018)
- Input Voltage AC Max: 265V
- Input Voltage AC Min: 85V
