MYRRA - 47255 - AC/DC PCB Mount Power Supply (PSU), ITE, 2 Output, 4 W, 15 V, 135 mA, 15 V
- No. of Outputs: 2 Output
- Output Power Max: 4W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 135mA
- Output Voltage - Output 2: 15V
- Output Current - Output 2: 135mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Fixed
- Input Voltage VAC: 85V AC to 265V AC
- Width: 26.7mm
- Height: 21.8mm
- Depth: 31.7mm
- Product Range: 47000 Series
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: EN, UL
- Input Voltage AC Max: 265VAC
- Input Voltage AC Min: 85VAC
- No. of Outputs: 2Outputs
