description
MYRRA - 47206 - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 7.5 W, 3.3 V, 2.27 A
- No. of Outputs: 1 Output
- Output Power Max: 7.5W
- Output Voltage - Output 1: 3.3V
- Output Current - Output 1: 2.27A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Fixed
- Input Voltage VAC: 85V AC to 265V AC
- Width: 41mm
- Height: 24.5mm
- Depth: 35mm
- Product Range: 47000 Series
- SVHC: No SVHC (27-Jun-2018)
- Input Voltage AC Max: 265VAC
- Input Voltage AC Min: 85VAC
- Output Current Max: 2.27A
