BOURNS - 4610X-101-332LF - Fixed Network Resistor, 3.3 kohm, Bussed, 9 Resistors, SIP, PC Pin, ± 2%
- Resistance: 3.3kohm
 - Product Range: 4600X Series
 - No. of Elements: 9Elements
 - Network Circuit Type: Bussed
 - Resistor Case Style: SIP
 - No. of Pins: 10Pins
 - Voltage Rating: 100V
 - Power Rating per Element: 200mW
 - Resistance Tolerance: ± 2%
 - Temperature Coefficient: ± 100ppm/°C
 - Automotive Qualification Standard: -
 - SVHC: Lead (15-Jan-2019)
 - External Depth: 5.08mm
 - External Length / Height: 25.35mm
 - External Width: 2.49mm
 - Full Power Rating Temperature: 70°C
 - Insulation Resistance: 10Mohm
 - Lead Length: 3.43mm
 - Lead Spacing: 2.54mm
 - Operating Temperature Max: 125°C
 - Operating Temperature Min: -55°C
 - Operating Temperature Range: -55°C to +125°C
 - Power Rating: 1.25W
 - Resistance R1: 3.3kohm
 - Resistor Element Material: Thick Film
 - Resistor Mounting: Through Hole
 - Resistor Terminals: Radial Leaded
 - Temperature Coeff Tracking +: 50ppm/°C
 - Temperature Coeff Tracking -: 50ppm/°C
 - Temperature Coeff. +: 100ppm/°C
 - Temperature Coeff. -: 100ppm/°C
 - Tolerance +: 2%
 - Tolerance -: 2%
 - Voltage Rating V DC: 100V
