description
MYRRA - 45028 - PCB Transformer, UI 30 x 10.5, Encapsulated Safety Isolating, 115V, 230V, 2 x 15V, 6 VA
- Power Rating: 6VA
- Secondary Voltages: 2 x 15V
- Current Rating: 200mA
- Isolation Transformer Primary Voltages: 1 x 115V, 1 x 230V
- Plug Type: -
- Product Range: 45000 Series
- SVHC: No SVHC (27-Jun-2018)
- AC Power: 6VA
- External Depth: 44mm
- External Length / Height: 22mm
- External Width: 53mm
- Input Voltage: 230V
- Output Voltage: 15V
- Primary Voltages: 115V to 230V
- Secondary Current Nom: 200mA
- Secondary Power: 3VA
- Transformer Type: Encapsulated
