description
- Network Circuit Type: Bussed
- No. of Resistors: 9Resistors
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Power Rating: 1.25W
- Power Rating per Resistor: 200mW
- Product Height: 4.95mm
- Product Length: 24.99mm
- Product Range: 4300R Series
- Product Width: 2.16mm
- Qualification: -
- Resistance: 100kohm
- Resistance Tolerance: ± 2%
- Resistor Case / Package: SIP
- Resistor Mounting: Through Hole
- Resistor Technology: Thick Film
- Resistor Terminals: PC Pin
- Resistor Type: Network
- Temperature Coefficient: ± 100ppm/°C
- Terminal Pitch: 2.54mm
