VAN DAMME - 268002C - Multicore Cable, Pro Grade Flex, Per M, Screened, 2 Core, 24 AWG, 0.22 mm²
- Cable Shielding: Screened
- No. of Cores: 2Core
- Wire Gauge: 24AWG
- Conductor Area CSA: 0.22mm²
- Reel Length (Imperial): -
- Reel Length (Metric): -
- Jacket Colour: Blue
- No. of Max Strands x Strand Size: 7 x 0.2mm
- Conductor Material: Copper
- Jacket Material: PVC
- External Diameter: 3.5mm
- Voltage Rating: -
- Product Range: -
- SVHC: No SVHC (27-Jun-2018)
- Cable Type: Shielded
- Core - Core Capacitance: 90pF/m
- Core-Screen Capacitance: 189pF/m
- Operating Temperature Max: 70°C
- Operating Temperature Min: -25°C
- Resistance per Metre: 0.078ohm
