WIELAND ELECTRIC - 25.195.1253.0 - Wire-To-Board Terminal Block, 3.5 mm, 12 Ways, 30 AWG, 16 AWG, 1.5 mm², Screw
- Pitch Spacing: 3.5mm
- No. of Positions: 12Ways
- Wire Size AWG Min: 30AWG
- Wire Size AWG Max: 16AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: 10A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, PCB
- Contact Material: Bronze
- Contact Plating: Tin Plated Contacts
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Voltage Rating VAC: 160V
- Wire Area Size Max: 1mm²
