MASCOT - 2386000042 - DC/AC Inverter, ITE, 15 VDC, 230 V, 600 W, 2386 Series
- Input Voltage Max: 15VDC
- No. of Outputs: -
- Output Voltage: 230V
- Output Power: 600W
- Product Range: -
- Length: -
- Width: 252 mm
- Height: 80mm
- SVHC: No SVHC (15-Jan-2019)
- Efficiency: 90%
- External Depth: 238mm
- External Length / Height: 83mm
- External Width: 252mm
- Input Current Min: 1.4A
- Input Voltage: 12VDC
- Input Voltage Min: 10VDC
- Power Rating: 600W
- Supply Voltage: 12V
- Supply Voltage Max: 15V
- Supply Voltage Min: 10V
- Surge Power Rating: 600W
