description
PHOENIX CONTACT - 2320102 - Isolated DIN Rail Mount DC/DC Converter, ITE, 2:1, 400 W, 1 Output, 24 V, 20 A
- No. of Outputs: 1 Output
- Output Power Max: 400W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 20A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: Quint Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 32V
- DC / DC Converter Mounting: DIN Rail
- DC / DC Converter Output Type: Fixed
- SVHC: Lead (15-Jan-2019)
- Approvals & Standards: UL
- Output Current Max: 20A
- Output Voltage Nom.: 24V
