FINDER - 22.32.0.012.4320 - Contactor, DIN Rail, 250 VAC, DPST-NO, 2 Pole
- Load Current Inductive: -
- Relay Mounting: DIN Rail
- Operating Voltage: 250VAC
- Contact Configuration: DPST-NO
- No. of Poles: 2 Pole
- Switching Power AC3: -
- Switching Current AC1: -
- Coil Voltage VAC Nom: 12V
- Coil Voltage VDC Nom: 12V
- Switching Power AC1: 1kW
- Load Current Resistive: 25A
- Switching Current AC3: 10A
- Product Range: 22 Series
- SVHC: No SVHC (15-Jan-2019)
- Approvals & Standards: CE
- Coil Voltage: 12V
- Contact Current: 25A
- Contact Current Max: 25A
- Contact Material: Silver Nickel
- Contact Voltage AC Nom: 250V
- Contact Voltage VAC: 250V
- External Depth: 60.8mm
- External Height: 84mm
- External Width: 17.5mm
- Nom Operating Power: 2VA
- Operating Temperature Max: 50°C
- Operating Temperature Min: -20°C
- Relay Terminals: Screw
- Relay Type: Modular
- Termination Type: Screw
