description
PANASONIC - 16SEPC100MW - Polymer Aluminium Electrolytic Capacitor, 100 µF, 16 V, 0.01 ohm, 5000 hours @ 105°C, ± 20%
- Capacitance: 100µF
- Voltage Rating: 16V
- AE Capacitor Case: -
- Product Range: OS-CON SEPC Series
- ESR: 0.01ohm
- Lifetime @ Temperature: 5000 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 6.3mm
- Height: 9mm
- Lead Spacing: 2.5mm
