VISHAY - 138B00103B05 - Rotary Potentiometer, Conductive Plastic, 10 kohm, 1 Turns, Linear, 2 W, ± 10%, 138B
- Track Resistance: 10kohm
- No. of Turns: 1Turns
- Track Taper: Linear
- Power Rating: 2W
- Resistance Tolerance: ± 10%
- Product Range: 138B Series
- Potentiometer Mounting: Bushing
- Shaft Diameter: 6.34mm
- No. of Gangs: 1
- Adjustment Type: Rotary
- Shaft Length: 22.22mm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Resistor Element Material: Conductive Plastic
- Temperature Coefficient: ± 500ppm/°C
- Termination Type: Solder
