RAFI - 1.15.106.502/1500 - Industrial Pushbutton Switch, Green, 9.1 mm, SPST-NO, SPST-NC, Momentary, Round, Transparent
- Product Range: -
- Contact Configuration: SPST-NO, SPST-NC
- Switch Operation: Momentary
- Contact Current Max: 500mA
- Contact Voltage AC Nom: -
- Illumination Colour: Green
- Contact Voltage DC Nom: -
- Switch Terminals: Solder Lug
- Actuation Type: Round
- Actuator / Cap Colour: Transparent
- Colour: Green
- Contact Current AC Max: 500mA
- Contact Current DC Max: 500mA
- Contact Voltage VAC: 24V
- Contact Voltage VDC: 24V
- External Depth: 25mm
- External Length / Height: 7mm
- IP Rating: IP40
- Operating Force: 5N
- Operating Temperature Max: 55°C
- Operating Temperature Min: -25°C
- Panel Cutout Diameter: 9.1mm
- Pushbutton Actuator Style: Round
- Pushbutton Switch Type: Standard
- Switch Mounting: Panel
