EPIC - 10.1920 - Heavy Duty Connector, Insert, EPIC HBE Series, Cable Mount, Plug, 10 Contacts, Pin, 2 Rows
- Product Range: EPIC HBE Series
- Connector Mounting: Cable Mount
- Gender: Plug
- No. of Contacts: 10Contacts
- Contact Gender: Pin
- No. of Rows: 2Rows
- Contact Termination Type: Screw
- Connector Shell Size: -
- Contact Material: Copper Alloy
- Contact Plating: Silver Plated Contacts
- SVHC: No SVHC (15-Jan-2019)
- Connector Type: Rectangular Power
- Contact Termination: Screw
- Current Rating: 16A
- Degree of Pollution: 3
- IP / NEMA Rating: IP65
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Range: HB10
- Termination Method: Screw
- Test Voltage: 6kV
- Voltage Rating VAC: 400V
- Wire Area Size Max: 2.5mm²
- Wire Area Size Min: 0.5mm²
- Working Voltage: 400V
