VISHAY - VS-409CNQ150PBF - Diode Module, 150 V, 400 A, 850 mV, Dual Common Cathode, TO-244, 3 Pins
- Repetitive Reverse Voltage Vrrm Max: 150V
- Forward Current If(AV): 400A
- Forward Voltage VF Max: 850mV
- Diode Module Configuration: Dual Common Cathode
- Product Range: VS-40 Series
- Avalanche Single Pulse Energy Eas: 190mJ
- Current Ifsm: 20kA
- Current Temperature: 128°C
- Diode Case Style: TO-244
- Diode Configuration: Dual Common Cathode
- Diode Type: Schottky
- Forward Surge Current Ifsm Max: 20kA
- Forward Voltage: 1.21V
- Junction Temperature Tj Max: 175°C
- No. of Pins: 3Pins
- Operating Temperature Max: 175°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +175°C
- Termination Type: Screw
