BOURNS - SRP1270-6R8M - Power Inductor (SMD), 6.8 µH, 12 A, Shielded, 21 A, SRP1270
- Inductance: 6.8µH
- RMS Current (Irms): 12A
- Inductor Construction: Shielded
- Saturation Current (Isat): 21A
- Product Range: SRP1270 Series
- Power Inductor Case: 13.7mm x 13.7mm x 7mm
- DC Resistance Max: 0.014ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 13.7mm
- External Length / Height: 7mm
- External Width: 13.7mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Resonant Frequency: 12MHz
- Self Resonant Frequency Min: 12MHz
- Test Frequency: 100kHz
