Omschrijving
VISHAY - IHLP2020BZER3R3M01 - Power Inductor (SMD), 3.3 µH, 3.3 A, Shielded, 8.5 A
- Inductance: 3.3µH
- RMS Current (Irms): 3.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 8.5A
- Product Range: -
- Power Inductor Case: 5.49mm x 5.18mm x 2mm
- DC Resistance Max: 0.0855ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- External Depth: 5.18mm
- External Length / Height: 2mm
- External Width: 5.49mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
