XP POWER - IH1224S-H - Isolated Through Hole DC/DC Converter, ITE, 1:1, 2 W, 2 Output, 24 V, 42 mA
- No. of Outputs: 2 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 42mA
- Output Voltage - Output 2: -24V
- Output Current - Output 2: 42mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IH Series
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 7.62mm
- Height: 10.16mm
- Depth: 19.5mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 82%
- External Depth: 10.16mm
- External Length / Height: 19.81mm
- External Width: 7.62mm
- Input Voltage: 12V
- Isolation Voltage: 3kV
- No. of Outputs: 2Outputs
- Off Load Current: 20mA
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Current - Max: 42mA
- Output Ripple Voltage pk-pk: 60mV
- Output Voltage +: 24V
- Output Voltage -: 24V
- Output Voltage Max: 24V
- Output Voltage Min: -24V
- Power Rating: 2W
- Supply Voltage: 12V
