Omschrijving
XP POWER - IF1212S - Isolated Through Hole DC/DC Converter, Regulated, ITE, 1:1, 1 W, 1 Output, 12 V, 84 mA
- No. of Outputs: 1 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 84mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 7.2mm
- Height: 10mm
- Depth: 19.5mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 68%
- External Depth: 10mm
- External Length / Height: 19.5mm
- External Width: 7.2mm
- Input Voltage: 12V
- Isolation Voltage: 1kV
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Ripple Voltage pk-pk: 50mV
- Power Rating: 1W
- Supply Voltage: 12V
