BROADCOM - HCPL-3140-000E - Optocoupler, Gate Drive Output, 1 Channel, DIP, 8 Pins, 3.75 kV
- No. of Channels: 1 Channel
- Optocoupler Case Style: DIP
- No. of Pins: 8Pins
- Isolation Voltage: 3.75kV
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: CSA, UL, VDE
- CMR: 10kV/µs
- Input Current: 12mA
- No. of Channels: 1Channels
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +100°C
- Optocoupler Output Type: Gate Drive
- Output Voltage: 30V
- Peak Output Current: 0.4A
- Propagation Time H-L: 0.7µs
- Propagation Time L-H: 0.7µs
- Voltage Vcc Max: 30V
- Voltage Vcc Min: 10V
- Voltage Vcm: 1000V
