RUBYCON - 400VXH270MEFCSN25X35 - Electrolytic Capacitor, Snap-in, 270 µF, 400 V, ± 20%, Snap-In, 5000 hours @ 105°C
- Capacitance: 270µF
- Voltage Rating: 400V
- Product Range: VXH Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 25mm
- Lead Spacing: 10mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Height: 35mm
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- Operating Temperature Range: -25°C to +105°C
- Ripple Current AC: 1400mA
