Omschrijving
HENGSTLER - 0.868.165 - Totalizer, Type 868, 8 Digits, 24 Vdc, No Reset
- No. of Digits / Alpha: 8
- Digit Height: 4mm
- Supply Voltage Min: 21.6VDC
- Supply Voltage Max: 26.4VDC
- Panel Cutout Height: 27mm
- Panel Cutout Width: 52mm
- Operating Temperature Min: -10°C
- Operating Temperature Max: 50°C
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Count Speed Max: 25Hz
- Counting Speed: 25Hz
- External Depth: 72.5mm
- External Length / Height: 40mm
- External Width: 56mm
- Operating Temperature Range: -10°C to +50°C
- Panel Cutout Size: 27 x 52 mm
- Power Consumption: 2.5W
- Supply Voltage Range: 21.6V DC to 26.4V DC
- Supply Voltage V DC: 24VDC
