BLOCK - VB1.5/2/12 - PCB Transformer, EI 30 x 12.5, Encapsulated Safety Isolating, 230V, 2 x 12V, 1.5 VA, 50Hz / 60Hz
- Power Rating: 1.5VA
- Secondary Voltages: 2 x 12V
- Current Rating: 62mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 1.5VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 23.8mm
- External Length / Height: 32.3mm
- External Width: 27.3mm
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 20mm
- Input Voltage: 230V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Output 2 Voltage Max: 12V
- Output Voltage: 12V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 20mm
- Primary Voltages: 1 x 230V
- Regulation: 57%
- Secondary Power: 0.75VA
- Single Primary Voltage: 230V
- Transformer Type: Encapsulated
- Weight: 84g
