Description
YAGEO - RC2010JK-070RL - Zero Ohm Resistor, Jumper, 2010 [5025 Metric], Thick Film, 750 mW, 2 A, Surface Mount Device
- Resistor Case Style: 2010 [5025 Metric]
- Resistance: 0ohm
- Product Range: RC Series
- Voltage Rating: 200V
- Resistor Element Material: Thick Film
- Power Rating: 750mW
- Resistance Tolerance: -
- Temperature Coefficient: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Climatic Category: 55/125/56
- External Depth: 0.55mm
- External Length / Height: 5mm
- External Width: 2.5mm
- Full Power Rating Temperature: 70°C
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Reel Quantity: 4000
- Resistor Mounting: Surface Mount Device
- Temperature Coeff. +: 300ppm/°C
- Temperature Coeff. -: 300ppm/°C
- Tolerance +: 1%
- Tolerance -: 1%
- Voltage Rating V DC: 200V
- Voltage Rating VAC: 200V
