QS5U17TR MOSFET, N, VGS -2.5V ROHM

ROHMSKU: QS5U17TR Order code: 1525462

Price:
Sale price€1,92

Tax included Shipping calculated at checkout

Stock:
In stock (110 units), ready to be shipped

Documents et téléchargements

Description

ROHM - QS5U17TR - Power MOSFET, N Channel, 30 V, 2 A, 0.154 ohm, TSMT, Surface Mount

  • Transistor Polarity: N Channel
  • Continuous Drain Current Id: 2A
  • Drain Source Voltage Vds: 30V
  • On Resistance Rds(on): 0.154ohm
  • Rds(on) Test Voltage Vgs: 4.5V
  • Threshold Voltage Vgs: 1.5V
  • Power Dissipation Pd: 900mW
  • Transistor Case Style: TSMT
  • No. of Pins: 5Pins
  • Operating Temperature Max: 150°C
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: MSL 1 - Unlimited
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Ciss Typ: 175pF
  • Fall Time tf: 8ns
  • Pin Configuration: 1(G),2(S),3(A),4(K),5(D)
  • Pulse Current Idm: 8A
  • Rise Time: 10ns
  • Termination Type: Surface Mount Device
  • Transistor Type: Protected MOSFET
  • Voltage Vds Typ: 30V
  • Voltage Vgs Rds on Measurement: 2.5V
  • Voltage Vgs th Max: 1.5V
  • Voltage Vgs th Min: 500mV
