COILCRAFT Power Inductors - SMD MSS7341T-273MLD INDUCTOR, 27UH, 2.1A, 20%, PWR, 19MHZ COILCRAFT 2288698 MSS7341T-273MLD
Roll over image to zoom in Click on image to zoom
COILCRAFT Power Inductors - SMD MSS7341T-273MLD INDUCTOR, 27UH, 2.1A, 20%, PWR, 19MHZ COILCRAFT 2288698 MSS7341T-273MLD

MSS7341T-273MLD INDUCTOR, 27UH, 2.1A, 20%, PWR, 19MHZ COILCRAFT

COILCRAFTSKU: MSS7341T-273MLD Order code: 2288698
Price:
€5,00

Tax included Shipping calculated at checkout

Stock:
Sold out

Documenten en downloads

Description

COILCRAFT - MSS7341T-273MLD - Power Inductor (SMD), 27 µH, 2.1 A, Shielded, 1 A, MSS7341T, 7.3mm x 7.3mm x 4.1mm

  • Inductance: 27µH
  • RMS Current (Irms): 2.1A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 1A
  • Product Range: MSS7341T Series
  • Power Inductor Case: 7.3mm x 7.3mm x 4.1mm
  • DC Resistance Max: 0.109ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 19MHz
