COILCRAFT - MSS7331-104NLB - Power Inductor (SMD), 100 µH, 1.1 A, Shielded, 450 mA, MSS7331, 6.6mm x 6.6mm x 3.1mm
- Inductance: 100µH
- RMS Current (Irms): 1.1A
- Inductor Construction: Shielded
- Saturation Current (Isat): 450mA
- Product Range: MSS7331 Series
- Power Inductor Case: 6.6mm x 6.6mm x 3.1mm
- DC Resistance Max: 0.495ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
