Description
COILCRAFT - MSS6132-393MLC - Power Inductor (SMD), 39 µH, 1.45 A, Shielded, 790 mA, MSS6132
- Inductance: 39µH
- RMS Current (Irms): 1.45A
- Inductor Construction: Shielded
- Saturation Current (Isat): 790mA
- Product Range: MSS6132 Series
- Power Inductor Case: 6.1mm x 6.1mm x 3.2mm
- DC Resistance Max: 0.275ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 17MHz
