COILCRAFT - MSS5131-223MLC - Power Inductor (SMD), 22 µH, 1.3 A, Shielded, 540 mA, MSS5131
- Inductance: 22µH
- RMS Current (Irms): 1.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 540mA
- Product Range: MSS5131 Series
- Power Inductor Case: 5.1mm x 5.1mm x 3.1mm
- DC Resistance Max: 0.145ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 22MHz
