Description
SEPA - MFB30G05 - DC Axial Fan, 5 V, Square, 30 mm, 10 mm, Ball Bearing, 4.01 CFM
- Supply Voltage: 5V
- Current Type: DC
- Fan Frame Size: 30mm
- External Depth: 10mm
- Noise Rating: 21dBA
- Flow Rate - Imperial: 4.01cu.ft/min
- Flow Rate - Metric: 6.8m³/h
- Bearing Type: Ball
- Power Connection Type: 2 Lead Wires
- Current Rating: 130mA
- Product Range: MFB30G Series
- Power Rating: -
- IP Rating: -
- SVHC: No SVHC (15-Jan-2019)
- Blade Diameter: 28mm
- External Height: 30mm
- External Width: 30mm
- Fixing Centres: 24mm
- Fixing Hole Diameter: 3.2mm
- Frame Dimensions: 30mm x 30mm x 10mm
- Input Voltage Max: 5.5VDC
- Input Voltage Min: 4.5VDC
- Lead Length: 150mm
- Operating Temperature Max: 60°C
- Operating Temperature Min: -10°C
- Pressure Max: 20Pa
- Supply Voltage DC Max: 5.5V
- Supply Voltage DC Min: 4.5V
